Lifting Bags HLB

Lifting Bag HLB 2

• max. lifting capacity: 4721 lbf
• max. inflation height: 94 mm
• max. inflation height: 3.7 in
• thickness incl. profile: 22 mm
• thickness incl. profile: 0.9 in

Lifting Bag HLB 6

• max. lifting capacity: 12364 lbf
• max. inflation height: 141 mm
• max. inflation height: 5.6 in
• thickness incl. profile: 22 mm
• thickness incl. profile: 0.9 in

Lifting Bag HLB 8

• max. lifting capacity: 18434 lbf
• max. inflation height: 179 mm
• max. inflation height: 7 in
• thickness incl. profile: 22 mm
• thickness incl. profile: 0.9 in

Lifting Bag HLB 11

• max. lifting capacity: 24729 lbf
• max. inflation height: 207 mm
• max. inflation height: 8.2 in
• thickness incl. profile: 25 mm
• thickness incl. profile: 1 in

Lifting Bag HLB 16

Lifting Bag HLB 21

• max. lifting capacity: 47210 lbf
• max. inflation height: 266 mm
• max. inflation height: 10.5 in
• thickness incl. profile: 25 mm
• thickness incl. profile: 1 in

Lifting Bag HLB 31

• max. lifting capacity: 68792 lbf
• max. inflation height: 321 mm
• max. inflation height: 12.6 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in

Lifting Bag HLB 38

• max. lifting capacity: 83179 lbf
• max. inflation height: 352 mm
• max. inflation height: 13.9 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in

Lifting Bag HLB 53

• max. lifting capacity: 116901 lbf
• max. inflation height: 411 mm
• max. inflation height: 16.2 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in

Lifting Bag HLB 63

• max. lifting capacity: 139382 lbf
• max. inflation height: 456 mm
• max. inflation height: 18 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in

Lifting Bag HLB 85

• max. lifting capacity: 192212 lbf
• max. inflation height: 550 mm
• max. inflation height: 21.7 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in

Lifting Bag HLB 96

• max. lifting capacity: 211320 lbf
• max. inflation height: 565 mm
• max. inflation height: 22.2 in
• thickness incl. profile: 27 mm
• thickness incl. profile: 1.1 in
