Power Wedge PW 5624
| max. lifting height: | 51 mm |
| max. lifting height: | 2 in |
Features & benefits
- Can create an initial opening where other tools cannot
About the Power Wedge PW 5624
Specifications
Details
Article number
150.062.228
Basic specifications
model
PW 5624
equipped with (connector type)
CORE
max. working pressure
10443 psi
max. working pressure
720 / 72 (bar/Mpa)
Performance
max. spreading force
52830 lbf
min. insertion space
6 mm
min. insertion space
0.2 in
max. lifting height
51 mm
max. lifting height
2 in
max. spreading force
235 / 24 (kN/t)
Dimensions, weight and temperature
dimensions (AxBxC)
648 x 225 x 188 mm
dimensions (AxBxC)
25.5 x 8.9 x 7.4 in
weight, ready for use (EN13204:2025 & NFPA1960)
9.2 kg
weight, ready for use (EN13204:2025 & NFPA1960)
20.3 lb
Norms
EN 13204 2025 Ed classification
WE-235/50
AMCA 240-22 certified
6000 cycles
Features
Needs only 6 mm insertion height
- Can create an initial opening where other tools cannot
Lifting height 51 mm
- Enough to continue the rescue operation with a Holmatro spreader or lifting bag
Blades from spring steel with grooves
- Provides extra grip
Flexible synthetic protection cover over the blades
