About the Wedge HWJ 25 U
Specifications
Details
Article number
100.102.021
Basic specifications
model
HWJ 25 U
max. working pressure
10443 psi
max. working pressure
720 / 72 (bar/Mpa)
Performance
max. spreading force
235.4 kN / 24 t / 235.4 / 24 (kN/t)
max. spreading force
52920 lbf
tonnage
24 t
tonnage
52911 lb
min. insertion space
6 mm
min. insertion space
0.2 in
lifting stroke
51 mm
lifting stroke
2 in
General specifications
required oil content (press)
328 cc
required oil content (press)
11.1 oz
required oil content (retract)
217 cc
required oil content (retract)
7.3 oz
return type
hydraulic
Dimensions, weight and temperature
weight, ready for use
8.1 kg
weight, ready for use
17.9 lb
Features
Features & Benefits
- Minimum insertion space of 6 mm
- Compact construction
- Low weight
- Anti-skid profile on wedge arms
- Usable in all positions
