Hand Pump PA 100 H 2
Features & benefits
- Ergonomic design (1,2)
- Lightweight; easy to carry and operate
About the Hand Pump PA 100 H 2
Specifications
Details
Article number
101.000.331
Basic specifications
model
PA 100 H 2
max. working pressure
7977 psi
max. working pressure
550 / 55 (bar/Mpa)
Performance
number of stages
2
second stage pressure range
45 - 550 / 4.5 - 55 (bar/Mpa)
first stage pressure range
0 - 45 / 0 - 4.5 (bar/Mpa)
first stage output (per stroke)
50.5 cc
second stage output (per stroke)
4 cc
first stage output (per stroke)
1.71 oz
second stage output (per stroke)
0.14 oz
max. operating force
34 kg
max. operating force
75 lb
capacity oil tank
6150 cc
capacity oil tank (effective)
10000 cc
capacity oil tank
208 oz
capacity oil tank (effective)
338.1 oz
first stage pressure range
0 - 653 psi
second stage pressure range
653 - 7977 psi
General specifications
operator type
hand
connection
number of tool connections
2
double acting optional
yes
Dimensions, weight and temperature
weight, ready for use
21.2 kg
weight, ready for use
46.7 lb
Technical drawing dimensions
dimension A
1123 mm
dimension A
44.2 in
dimension B
210 mm
dimension B
8.3 in
dimension C
184 mm
dimension C
7.2 in
Features
Features & Benefits
- Ergonomic design (1,2)
- Lightweight; easy to carry and operate
- Low operating force required; minimal user effort
- Push & Unlock pump handle lock
- Service- and maintenance-friendly
- High oil output; quicker action both in the first and second stage
- Accurately adjustable pressure release valve (4)
- Pressure gauge connection on the pump block (5)
- Oil level glass in the tank; check the oil level in both horizontal and vertical position (6)
- Integrated filler funnel; top up oil easily and quickly without extra accessories (7)
