Cylinder HJ 50 G 6
About the Cylinder HJ 50 G 6
Specifications
Details
Article number
100.112.073
Basic specifications
model
HJ 50 G 6
max. working pressure
10443 psi
max. working pressure
720 / 72 (bar/Mpa)
Performance
tonnage
50 t
tonnage
110231 lb
stroke
60 mm
stroke
2.4 in
closed height
142 mm
closed height
5.6 in
capacity
510.3 kN / 52 t / 510.3 / 52 (kN/t)
capacity
114720 lbf
effective pressure area
70.9 cm2
effective pressure area
11 sq. in.
General specifications
required oil content (effective)
425 cc
required oil content (effective)
14.4 oz
acting type
single
return type
gravity
material
steel
cylinder type
high tonnage
connection
A 118
Dimensions, weight and temperature
weight, ready for use
12.5 kg
weight, ready for use
27.6 lb
Technical drawing dimensions
dimension A
142 mm
dimension A
5.6 in
dimension B
130 mm
dimension B
5.1 in
dimension C
80 mm
dimension C
3.1 in
dimension D
70 mm
dimension D
2.8 in
dimension E
20 mm
dimension E
0.8 in
dimension F
135 mm
dimension F
5.3 in
Features
Flat saddle; prevents damage to the plunger, easy to replace with tilting saddle
